สถานที่กำเนิด:
จีน
ชื่อแบรนด์:
YUYANG
ได้รับการรับรอง:
CE
หมายเลขรุ่น:
yy276
วิดีโอ
วิดีโอ
วิดีโอ
| Attribute | Value |
|---|---|
| Capacity | 500kg(5kN) |
| Force measurement | Within ±0.5% of the displayed value |
| Display method | Touch Screen |
| Unit | Kg, lb, N |
| Data sampling frequency | 200times/sec |
| Effective test width | 150mm |
| Effective stretching | 1200mm |
| Capacity | 500kg(5kN) |
| Force measurement accuracy | Within ±0.5% of the displayed value |
| Display method | Touch Screen |
| Unit | Kg, lb, N |
| Data sampling frequency | 200times/sec |
| Test machine resolution | Maximum load of 1/±25,000 yards, inside and outside without splitting, and constant resolution throughout |
| Load sensors | Basic configuration: pull and pressure sensors (maximum load) |
| Effective test width | 150mm |
| Effective stretching of space | 1200mm |
| Testing speed range | 1-100mm/min stepless speed control and 5-speed fixed (special test speed can be customized according to customer requirements) |
| Displacement measurement accuracy | Within ±0.5% of the displayed value |
| Breakpoint ratio setting | 0～99%, Users can set the appropriate breakage stop time according to different materials |
| Test bench safety device | Up and down travel limiter |
| Overload protection | Automatically protected when the maximum load is exceeded by 10% |
| Clamp | One set |
| Dimension | 550×400×1820mm |
| Main machine weight | About 100 Kgs |
| Power supply | 220V/50Hz |
| Compatible Software | Can provided according customers payment |
| Installation Instruction | Videos provided |
| Connect way | USB data cable connection |
